12BSS Stainless Steel Roller Chains
12BSS Stainless Steel Roller Chains Components
Inner and Outer Links:Roller chains usually have 2 sorts of links: internal links (roller links) and external web links (pin web links).
Rollers:Short, cylindrical rollers are a key component of the internal web links, promoting smooth involvement with sprockets and lowering rubbing.
Bushings (Sleeves):Bushings or sleeves are used to sustain the rollers within the internal web links.
Pins:Pins hold the outer links together and pass through the bushings of the internal web links.
Sprocket Engagement:The rollers of the chain engage with the teeth of a sprocket to send rotational movement.
12BSS Stainless Steel Roller Chains Product data information
| Model | unit | 12BSS |
| Pitch-(P) | mm | 19.05 |
| Roller Link Width（Min.)-(W min) | mm | 11.68 |
| Roller Outer Diameter(Max.)-(d1 max) | mm | 12.07 |
| Pin Outer Diameter-(d2 max) | mm | 5.72 |
| pin Length-(L max) | mm | 22.7 |
| pin Length-(lc max) | mm | 27.3 |
| Link Plate Height-(H max) | mm | 16.13 |
| Link Plate Thickness-(T) | mm | 1.8 |
| Minimum Tensile Strength-(min) | kgf | 2950 |
| Average Tensile Strength | kgf | 3350 |
Stainless Steel Roller Chains Built to Withstand the Harshest Environments
Quit allowing corrosion and environmental degradation compromise your machinery. Our Stainless Steel Roller Chains are the most typical and commonly made use of solution for a reason: they provide phenomenal performance in the harshest conditions. Made to operate throughout an exceptionally wide variety of temperature levels and applications, these chains are the workhorse of sectors where resilience is not just a benefit, but a requirement. Trust Fund our Stainless Steel Roller Chains to maintain your procedures running efficiently, securely, and effectively.
Advanced Materials Ensure Long-Term Strength in Stainless Steel Roller Chains
The durability of our Stainless Steel Roller Chains is forged from exceptional products and progressed modern technology. By utilizing state-of-the-art austenitic and martensitic stainless steel, we develop a chain with intrinsic resistance to both high and low temperatures, in addition to harsh compounds. This robust construction makes certain that the chain maintains its architectural stability and performance characteristics, whether it’s running in a freezer, an oven, or a chemical processing plant, making sure regular and reputable power transmission.
Wide Range of Stainless Steel Roller Chains for Every Application
Despite your certain requirement, we have a Stainless Steel Roller Chain to match. Our stock is one of the largest worldwide, covering whatever from ANSI, ISO, and DIN typical sizes to highly specialized configurations. We offer brief pitch roller chains for conventional drives, straight edge chains for stable conveying, double pitch chains for longer spans, and expanded pin chains for customized accessories. With a complete variety of accessories available, you can develop a full and customized system tailored to your precise needs.
Specialized Stainless Steel Roller Chains for Unique Industrial Challenges
We pride ourselves on having the excellent chain for every single consumer. Choose from our standard series, offered in 2 various tensile strengths, or explore our specialty alternatives for special challenges. We stock high-performance stainless-steel chains, costs 316-stainless steel roller chains for utmost corrosion defense, and even offer custom production solutions for really bespoke remedies. With our large option, locating the optimal Stainless Steel Roller Chain has never been less complicated.
Where to Use The 12BSS Stainless Steel Roller Chains
- Food Processing
- Dairy Products Processing
- Health Care
- Chemicalindustry
- Other Industries
Why Choose The 12BSS Stainless Steel Roller Chains
●Superior Corrosion Resistance
●Temperature Resilience
●Hygienic and Easy to Clean
●Low Magnetic Permeability
●Durable and Low Maintenance
●Customizable Sizes for Versatility
●Enhanced Performance Through Heat Treatment
Chart
Frequently Asked Question
Yes, they are extremely immune to saltwater corrosion, making them appropriate for aquatic usage.
Yes, we offer a total line of matching devices for all chain types and configurations.
We stock brief pitch, double pitch, straight side, expanded pin, and specialized chains.
No, they have reduced magnetic leaks in the structure, which is suitable for electronics and clinical industries.
Stainless-steel supplies better corrosion resistance and health, making it excellent for acidic, alkaline, or damp conditions.
Stainless-steel is commonly not as solid, however we enhance performance via warm therapy and pre-stressing.
