2023LW Silent Chain
2023LW Silent Chain Product data information
| Model | Unit | 2023LW |
| Pitch-（P) | mm | 6.35 |
| Roller Link width（Min.)-(W) | mm | 3.05 |
| Pin Link Plate Thickness-(T1) | mm | 0.70 |
| Inner link plate Thickness-(T2) | mm | 1.00 |
| Inner Link Plate Heinght-(H) | mm | 6.72 |
| Pin Diameter-(D) | mm | 2.72 |
| Overall Width Riv-(L) | mm | 6.10 |
| Minimum Tensile Strength | kgf | 520.00 |
| Average Tensile Strength | kgf | 620.00 |
What a Silent Chain Looks Like
A silent chain is made of many small metal pieces linked together. Each piece has two teeth, like little bumps, and they fit into a wheel to help things move. The chain looks flat and smooth, and it moves very quietly.
Why It Runs So Quiet
This chain doesn’t make much noise because the parts fit together really well. When machines are running fast, the silent chain doesn’t bang around or shake, so it stays quiet and works smoothly.
Strong Metal That Lasts Long
Silent chains are made from strong steel. They don’t break easily and can keep working for a long time. Even when machines run all day, the chain can still hold up without wearing out fast.
We Make Chains That Fit Your Machine
Every machine is different, so we can make silent chains in different sizes. If a machine needs to go fast or carry a lot of weight, we can build the chain to match. That way, everything works better and lasts longer.
Where to Use the 2023LW Silent Chain
- Automotive Engines
- Automotive Production lines
- Industrial Pumps,
- Textile Machinery
- Steel Rolling Transmissions
- Machine Tools
- Transfer Cases
- Steam Turbines
- Petroleum Machinery
Why Choose The 2023LW Silent Chain
●Not Affected by Atmospheric
●High Speeds
●Minimum of Maintenance
Chart
Frequently Asked Question
Yes, it can run very fast and still stay quiet and smooth.
Yes, it’s quieter and runs more smoothly than many other chains.
No. It bites very tightly and turns very steadily, and it is not easy to shake.
Because it is quiet, lasts a long time, and can run fast, it is a very easy-to-use chain.
If you pay attention to maintenance, it will not break easily and can be used for a long time.
静音链更安静、更稳定，适合需要安静的机器。
